The SSL-Techno Model and Master Model Solar Street Lights (50W–80W) by Ielecssol are advanced, durable, and energy-efficient outdoor lighting solutions designed for reliable performance in diverse environments. Built with premium components and cutting-edge technology, these systems deliver superior brightness, extended autonomy, and intelligent motion-based lighting control.
Engineered for critical applications and wide-area illumination, both models ensure complete independence from the electricity grid, making them ideal for remote locations, off-grid areas, or sites with limited power supply. Their rugged design and smart energy management guarantee long-lasting, dependable lighting for demanding outdoor conditions.
| LED Rated Power | 50W LED | 60W LED | 70W LED | 80W LED |
|---|---|---|---|---|
| Power of PV Module (W) Mono Perc | 150 Wp | 165 Wp | 200 Wp | 220 Wp |
| Lithium Battery Capacity (Lifepo4) | 12.8V , 48AH | 12.8V , 54AH | 12.8V , 66AH | 12.8V , 78AH |
| Typical Luminous Flux (Lm) | 7500 | 9000 | 10500 | 12000 |
| Colour Temperature(CCT) | 5700K - 6500K | 5700K - 6500K | 5700K - 6500K | 5700K - 6500K |
| Mounting Pole | Octagonal Pole | Octagonal Pole | Octagonal Pole | Octagonal Pole |
| Recommended Installation Height (Mtr.) | 7 Mtr. | 7 Mtr. | 8 Mtr. | 8 Mtr. |
| Charge Controller Type | MPPT | MPPT | MPPT | MPPT |
| Lenses Type | Glass With Lenses | Glass With Lenses | Glass With Lenses | Glass With Lenses |
| Driver Efficiency | > 93% | > 93% | > 93% | > 93% |
| Ingress Protection | IP65 | IP65 | IP65 | IP65 |
| No Load Current | Less than 20Amp | Less than 20Amp | Less than 20Amp | Less than 20Amp |
| Backup | 12 Hrs* | 12 Hrs* | 12 Hrs* | 12 Hrs* |
| Lighting Mode | Light will glow in 100 % Brightess for frist 4 Hrs & then , it will dim to 50% Brightess for balance 8 Hrs . | |||
| Protections | Battery Deep Discharge,Over charge Protection,Open Load Protection,Reverse Current Flow Protection,Short Circuit Protection and Temperature compensation. | |||
| Indication | Red LED Blink - Battery Low Green LED Blinking - Battery Charging Green LED Continuos Glow - Battery Full Charge |
|||
| Optional Features | Remote Ronitoring System (RMS) / CCTV Camera / PIR Sensor / Bluetooth / Hybrid | |||
| Techno | Master | |||
| Installation Diameter | ∅ 45 MM | ∅ 46 MM | ||
| Dimensions of Product (MM) | 371 X 130 X 70 MM | 550 X 275 X 100 MM | ||
| Gross Weight of Product (Kg) | 2.240 Kg | 3.4 Kg | ||
| Master Packing | 12 Nos 1 in Master Box | 4 Nos 1 in Master Box | ||
| Dimensions of Master Packing (MM) | 400 X 450 X 460 MM | 575 X 280 X 500 MM | ||
| Weight - Master Packing | 28.4 Kg | 14 Kg | ||
