The Solar Street Light Model Mini All-in-One (6W – 18W) is an integrated lighting solution that combines high-efficiency solar panels, long-lasting lithium batteries, intelligent motion sensors, and powerful LED lighting into one compact unit. Designed for ease of installation and maintenance, this system offers an eco-friendly and cost-effective alternative to traditional street lighting.
| LED Rated Power | 6W LED | 10W LED | 15W LED | 18W LED |
|---|---|---|---|---|
| Power of PV module (W) Mono Perc | 6 Wp | 13 Wp | 25 Wp | 52 Wp |
| Lithium Battery Capacity (LifePO4) | 3.2V , 6AH | 3.2V , 12AH | 3.2V , 18AH | 12.8V ,18AH |
| Typical Luminous Flux (Lm) | 900 | 1500 | 2250 | 2700 |
| Colour Temperature (CCT) | 3000K - 6500K | 3000K - 6500K | 3000K - 6500K | 3000K - 6500K |
| Backup | 12-15 Hrs* | 12-15 Hrs*- | 12-15 Hrs*- | 12-15 Hrs*- |
| Body Type | ABC & PC | Aluminium Die Casting | ||
| Lenses Tpye | Lenses | Lenses | Lenses | Lenses |
| Ingress Protection | IP 65 | IP 65 | IP 65 | IP 65 |
| IK | IK 10 | IK 10 | IK 10 | IK 10 |
| Lighting Model | Light Will Glow in Full Bright Mode 100% For 4 Hrs & After 4 Hrs Light Will Dim to 50% Brightness For 8 Hrs | |||
| Indication | Red LED Blink - Battery Low Green LED Blinking - Battery Green LED Continuos Glow-Battery Full Charge |
|||
